hammer crusher

　　Application: It can be used to crush medium hardness or crisp materials in mine, cement, coal, metallurgy, building material, road industries. The discharging size can be adjusted according to the specific requirement.

　　Suitable material: It can crush medium hardness and weak corrosive material with compression strength less than 100Mpa. The water content should be less than 15%. The material can be coal, salt, plaster, brick, limestone etc.

立即订购

产品特点

　Features:

　　1. Easy structure, high broke ratio and productivity.

　　2. It has dry and wet crushing modes.

　　3. It can be used in crush production line, sand production line and also can replace the cone crusher in sand choosing production line.

工作原理

　Working principles: the motor drives the rotor to rotate at high speed in the crushing chamber. The materials fed from the upper part of the crusher, are impacted, sheared and crushed by the high speed rotating hammer. At the lower part, the screening plates are equipped, which allow the materials less then the sieve discharge; and the materials over the sieve are left on the screening plate to be continuously impacted and crushed by the hammer, finally it’s discharged.

技术参数

Specification model	Speed	Feed particle size	Grain size	Yield	Weight	Power	Dimensions
PC-400×300	1450	≤100	10	3-10	0.8	11	812×9827×85
PC-500×350	1250	≤100	15	5-15	1.2	18.5	1200×1114×1114
PC-600×400	1000	≤220	15	5-25	1.5	22	1055×1022×1122
PC-800×600	980	≤350	15	10-50	3.1	55	1360×1330×1020
PC-800×800	980	≤350	15	10-60	3.5	75	1440×1740×1101
